how to install patio door without nailing flange

Installing a patio door without a nailing flange is often referred to as a “flush fin” or “block frame” installation. This method is commonly used when you’re replacing an existing patio door or when the door doesn’t have a nailing flange. Here’s a step-by-step guide on how to install a patio door without a nailing flange:

Materials You’ll Need:

  1. Patio door
  2. Measuring tape
  3. Level
  4. Shims
  5. Screws
  6. Drill/driver
  7. Caulk and caulk gun
  8. Exterior trim (optional)
  9. Interior trim (optional)

Step 1: Measure and Prepare the Opening

  • Measure the width and height of the existing door opening to ensure that the new patio door will fit.
  • Remove the existing door and any trim, if applicable.

Step 2: Check the Opening for Level and Plumb

  • Use a level to check the sill (bottom) and jambs (sides) of the door opening for level and plumb. Make any necessary adjustments using shims to ensure that the opening is square and level.

Step 3: Prepare the Door

  • Remove any packaging, protective film, or shipping materials from the new patio door.
  • Apply a bead of caulk along the exterior perimeter of the door frame where it will contact the opening. This will create a waterproof seal.

Step 4: Insert the Door

  • Carefully lift the patio door and insert it into the prepared opening. It’s helpful to have a helper for this step.
  • Ensure that the door is centered within the opening both horizontally and vertically.

Step 5: Shim and Level the Door

  • Insert shims between the door frame and the opening at various points along the sides and bottom of the door frame to provide support and maintain the desired positioning.
  • Use a level to ensure that the door is plumb and level. Make any necessary adjustments by adding or removing shims.

Step 6: Secure the Door

  • Once the door is level and properly shimmed, drill pilot holes through the door frame into the surrounding framing at several locations. Be sure to drill into solid wood or structural framing members.
  • Drive screws through the pilot holes to secure the door in place. Make sure the screws are long enough to penetrate into the structural framing for a secure fit.

Step 7: Check for Smooth Operation

  • Open and close the door to ensure it operates smoothly without any binding or sticking. Make any necessary adjustments to the shims if needed.

Step 8: Apply Exterior and Interior Trim (Optional)

  • Install exterior trim around the patio door on the outside of the house to cover any gaps between the door frame and the opening. Caulk the trim and seams for a weatherproof seal.
  • Install interior trim on the inside of the house to cover the gap between the door frame and the wall. Caulk and finish the trim as desired.

Step 9: Finish and Seal

  • Apply a bead of exterior caulk around the perimeter of the patio door frame on the exterior side to create a weatherproof seal.
  • Apply interior caulk around the door frame on the interior side for a finished look and added insulation.

By following these steps, you can successfully install a patio door without a nailing flange. Ensure that the door is plumb, level, and properly sealed to prevent drafts and water infiltration. If you’re unsure about any part of the installation, it’s a good idea to consult a professional for assistance.
